The sliding 24-port fiber distribution panel can be configured with SC, LC, FC, or ST plates based on the needs of the application. It is designed to enable the connection between external optical cables and pigtails. To prevent damage to the fiber optic cable, it contains four cable entrance holes on the back that are equipped with rubber grommets. The rack mount fiber patch panel offers a single 24F splice tray and routing spool inside the enclosure for convenient fiber operation. Its pull-out design, sensible arrangement, and sufficient room make it straightforward to install and maintain.
For rack-mount installation, this sliding fiber patch panel can be pre-terminated with adapters (such as sc, fc, lc, and st) and a 24-strand pigtail. The cable can be single-mode or multimode depending on your actual solution. In fiber termination and distribution applications, such as FTTH, FTTB, data centers, and telecom networks, the 24 port rack mount patch panel performs exceptionally well.
Technical index:
- Fiber curvature radius ≥40 mm
- Additional fiber tray loss: none
- Fiber length remaining in the tray: ≥1.6 meters
- Operating temperature: -5°C to +40°C
- Maximum tensile strength ≥500N
- Crush force greater than 200N
Specification:Size(mm) 482*300*44.5 (1U) Suitable adapters SC, ST, FC, LC Cable inlet/outlet 4/24 Connector capacity 24 or 48 Max fiber splice capacity 24 (single core) or 48 (dual core) Application FTTH, LAN, WAN, CATV etc Lead Time 7 days for 100pcs, 20 days for 300pcs MOQ 50pcs
