For optical networks, the rotary 24 port fibre patch panel with splice tray is made to offer dependable fibre termination, splicing, and distribution. It is the perfect option for structured cabling applications since it makes it possible to link Ethernet switches, OSP cables, and building cabling systems effectively. This fibre patch panel’s basic 1U rack mount design provides a small yet roomy interior for simple installation and upkeep. It can be installed in 19 or 23-inch server racks and network cabinets and is frequently used for branch connections of fibre optic cables.
The panel offers safe fibre splicing, organised storage of extra fibres, and support for up to 24 fibre terminations thanks to its integrated splice tray. In order to maintain the appropriate bend radius and guarantee long-term fibre protection, the unit also has cable management spools. Multiple adaptor types, such as SC, LC, FC, and ST, are supported by this swing-out fibre patch panel with splice tray, providing flexibility for various network requirements. To ensure neat and effective cable management, patch cords are routed from the front through the adapter panel, while optical cables enter from the back.
The distribution panel can be pre-terminated with 24-strand single-mode or multimode fibre pigtails for quicker deployment, which will speed up installation and increase overall effectiveness. Stable performance in data centers, telecom rooms, and enterprise network environments is guarantyd by its sturdy steel construction.
Features:
- The body’s surface is electrostatically sprayed and composed of premium cold-rolled steel.
- Set up with a splice tray, thread ring, and cable fixed device; an overlying splice tray is handy for future capacity extension.
- The safety is provided by an independent insulation grounding device.
- The internal splice tray is composed of engineered polymers with excellent strength.
Technical Index: - Radius of optical fibre winding: ≥40 mm
- Additional fibre tray loss: none
- Fibre length remaining in the tray: ≥1.6 m
- Temperature of operation: -400C to +600C
- 500N lateral pressure-resistance750N shock resistance
